Satuan Suhu Sedang hingga Tinggi Hanbell
Unit sekrup suhu sedang hingga tinggi Hanbell adalah solusi pendinginan terintegrasi dengan efisiensi tinggi yang dirancang khusus untuk aplikasi suhu penguapan sedang hingga tinggi. Unit ini menekankan stabilitas sistem, keandalan operasional, dan kemudahan penggunaan dalam proyek teknik. Ini memiliki struktur kompak dan lengkap yang sangat mengintegrasikan kompresor sekrup, pemisah oli, pendingin oli, penerima cairan, economizer, pengontrol tekanan, dan kabinet kontrol listrik. Selain itu, dilengkapi dengan rangka modular, katup penutup, katup periksa, katup pengaman, dan sistem injeksi oli, sehingga menghasilkan unit pendingin yang berfungsi penuh langsung dari pabrik. Desain terintegrasi ini menyederhanakan instalasi dan commissioning di lokasi, sehingga meningkatkan efisiensi proyek.
Unit ini dikonfigurasikan secara komprehensif, dengan semua komponen pendingin utama dan elemen kontrol bersumber dari merek terkemuka untuk memastikan pengoperasian yang terkoordinasi antar komponen, meningkatkan keandalan sistem secara keseluruhan dan keselamatan operasional. Desain rangka modular memberikan fleksibilitas untuk perluasan atau pemeliharaan di masa mendatang, mengurangi kompleksitas operasional dan pemeliharaan secara keseluruhan sekaligus memastikan kinerja yang konsisten dalam kondisi suhu sedang hingga tinggi.
Pengenalan Parameter Peralatan
Tampilan Detail
Hubungi Kami
Pengenalan Parameter Peralatan
| Model Satuan | Com.Model | Com, Keakuratan | Kondensasi suhu. (℃) | Suhu Penguapan. (℃) | waduk (kiri) | Pasokan pipa (mm) | Hisap pipa (mm) | Jalan Keluar Gas pipa (mm) | cair pipa masuk (mm) | Dimensi (mm) (PxL×T) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasitas Pendinginan/Input Daya (kw) | |||||||||||||||||||
| LXPL-BHF-30M | RC2-100B -Z (30HP) | 1 | 35 | 47. | 18.7 | 38.1 | 19.4 | 70.6 | 20.1 | 85.2 | 20.7 | 101.2 | 21.2 | 80 | Φ28 | Φ54 | Φ42 | Φ35 | 1700×900×1100 |
| 40 | 43.8 | 20.4 | 34.1 | 21.2 | 66.4 | 22.0 | 80.3 | 22.7 | 96.4 | 23.3 | |||||||||
| 45 | 40.3 | 22.2 | 50.0 | 23.1 | 61.6 | 24.0 | 74.8 | 24.8 | 90.4 | 25.3 | |||||||||
| LXPL-BHF2 -60M | RC2-100B -ZP (30HP) | 2 | 35 | 94.2 | 37.4 | 116.2 | 38.8 | 141.2 | 40.2 | 170.4 | 41.4 | 202.4 | 42.4 | 100 | Φ35 | Φ89 | Φ54 | Φ35 | 2300×1700×1800 |
| 40 | 87.6 | 40.8 | 108.2 | 42.4 | 132.8 | 44.0 | 160.6 | 45.4 | 192.8 | 46.6 | |||||||||
| 45 | 80.6 | 44.4 | 100.0 | 46.2 | 123.2 | 48.0 | 149.6 | 49.6 | 180.8 | 50.6 | |||||||||
| LXPL-BHF3 -90M | 3 | 35 | 141.3 | 56.1 | 174.3 | 58.2 | 211.8 | 60.3 | 255.6 | 62.1 | 306.3 | 63.6 | 150 | Φ42 | Φ89×2 | Φ54 | Φ42 | 3000×1700×1800 | |
| 40 | 131.4 | 61.2 | 162.3 | 63.6 | 1992 | 66.0 | 240.9 | 68.1 | 289.2 | 69.9 | |||||||||
| 45 | 120.9 | 66.6 | 150.0 | 69.3 | 184.8 | 72.0 | 224.4 | 74.4 | 271.2 | 75.9 | |||||||||
| LXPL-BHF4 -120 juta | 4 | 35 | 188.4 | 74.8 | 232.4 | 77.6 | 282.4 | 80.4 | 340.8 | 82.8 | 408.4 | 84.8 | 200 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 3700×1700×1800 | |
| 40 | 1752 | 81.6 | 216.4 | 84.8 | 265.6 | 88.0 | 321.2 | 90.8 | 385.6 | 93.2 | |||||||||
| 45 | 161.2 | 88.8 | 200.0 | 92.4 | 246.4 | 96.0 | 299.2 | 99.2 | 361.6 | 101.2 | |||||||||
| LXPL-HF -40M | RC2-140B -Z (40HP) | 1 | 35 | 65.1 | 24.4 | 80.2 | 25.4 | 97.6 | 26.3 | 117.8 | 271.0 | 141.0 | 27.8 | 80 | Φ28 | Φ54 | Φ42 | Φ35 | 1730×700×1100 |
| 40 | 60.7 | 26.6 | 74.9 | 27.7 | 91.7 | 28.7 | 110.9 | 29.6 | 133.2 | 30.4 | |||||||||
| 45 | 55.9 | 29.1 | 69.3 | 30.3 | 85.2 | 31.4 | 103.4 | 32.5 | 124.9 | 33.4 | |||||||||
| LXPL-BHF2 -80M | RC2-140B -ZP (40HP) | 2 | 35 | 130.2 | 48.8 | 160.4 | 50.8 | 1952 | 52.6 | 235.6 | 54.2 | 282.0 | 55.6 | 150 | Φ35 | Φ108 | Φ54 | Φ35 | 2300×1700×1800 |
| 40 | 121.4 | 53.2 | 149.8 | 55.4 | 183.4 | 57.4 | 221.8 | 59.2 | 266.4 | 60.8 | |||||||||
| 45 | 111.8 | 58.2 | 138.6 | 60.6 | 170.4 | 62.8 | 206.8 | 65.0 | 249.8 | 66.8 | |||||||||
| LXPL-BHF3 -120 juta | 3 | 35 | 195.3 | 73.2 | 240.6 | 76.2 | 292.8 | 78.9 | 353.4 | 81.3 | 423.0 | 83.4 | 200 | Φ42 | Φ89×2 | Φ76 | Φ42 | 3000×1700×1800 | |
| 40 | 182.1 | 79.8 | 224.7 | 83.1 | 275.1 | 86.1 | 332.7 | 88.8 | 399.6 | 91.2 | |||||||||
| 45 | 167.7 | 87.3 | 207.9 | 90.9 | 2556 | 94.2 | 310.2 | 97.5 | 374.7 | 100.2 | |||||||||
| LXPL-BHF4 -160M | 4 | 35 | 260.4 | 97.6 | 320.8 | 101.5 | 309.4 | 105.2 | 471.2 | 108.4 | 564.0 | 111.2 | 250 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 3800×1700×1800 | |
| 40 | 242.8 | 106.4 | 299.6 | 110.8 | 366.8 | 114.8 | 443.6 | 118.4 | 532.8 | 121.6 | |||||||||
| 45 | 223.6 | 116.4 | 277.2 | 121.2 | 340.8 | 125.6 | 413.6 | 130.0 | 499.6 | 133.6 | |||||||||
| LXPL-HF -50 juta | RC2-180B -Z (50HP) | 1 | 35 | 85.9 | 30.3 | 105.3 | 31.5 | 128.1 | 32.6 | 154.6 | 33.6 | 185.1 | 34.5 | 100 | Φ35 | Φ67 | Φ42 | Φ35 | 2300×900×1100 |
| 40 | 79.8 | 33.1 | 98.4 | 34.4 | 120.4 | 35.7 | 145.6 | 36.8 | 174.8 | 37.8 | |||||||||
| 45 | 73.6 | 36.1 | 91.1 | 37.6 | 112.3 | 39.0 | 136.2 | 40.3 | 163.9 | 41.5 | |||||||||
| LXPL-BHF2 -100 juta | RC2-180B -ZP (50HP) | 2 | 35 | 171.8 | 60.6 | 210.6 | 63.0 | 2562 | 652 | 309.2 | 67.2 | 370.2 | 69.0 | 200 | Φ42 | Φ108 | Φ76 | Φ42 | 2300×1700×1800 |
| 40 | 159.6 | 66.2 | 195.8 | 88.8 | 240.8 | 74.1 | 291.2 | 73.6 | 349.6 | 75.6 | |||||||||
| 45 | 147.2 | 72.2 | 182.2 | 75.2 | 224.6 | 78.0 | 272.4 | 80.6 | 327.8 | 83.0 | |||||||||
| LXPL-BHF3 -150 juta | 3 | 35 | 257.7 | 90.9 | 315.9 | 94.5 | 384.3 | 97.8 | 463.8 | 100.8 | 555.3 | 103.5 | 250 | Φ54 | Φ89×2 | Φ76 | Φ54 | 3500×1700×1800 | |
| 40 | 239.4 | 99.3 | 295.2 | 103.2 | 361.2 | 107.1 | 436.8 | 110.4 | 524.4 | 113.4 | |||||||||
| 45 | 220.8 | 108.3 | 273.3 | 112.8 | 336.9 | 117.0 | 408.6 | 120.9 | 491.7 | 124.5 | |||||||||
| LXPL-BHF4 -200 juta | 4 | 35 | 343.5 | 121.2 | 421.2 | 126.0 | 512.4 | 130.4 | 618.4 | 134.4 | 740.4 | 138.0 | 300 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 4400×1700×1800 | |
| 40 | 319.2 | 132.4 | 393.8 | 137.6 | 481.6 | 142.8 | 582.4 | 147.2 | 699.2 | 151.2 | |||||||||
| 45 | 294.4 | 144.4 | 364.4 | 150.4 | 449.2 | 156.0 | 544.8 | 161.2 | 655.6 | 166.0 | |||||||||
| Model Satuan | Com.Model | Com. Ketelitian | Kondensasi suhu. (℃) | Suhu Penguapan (℃) | waduk (kiri) | Pasokan pipa (mm) | Hisap pipa (mm) | Jalan Keluar Gas pipa (mm) | cair pipa masuk (mm) | Dimensi (mm) (P×L×T) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasitas Pendinginan/Input Pewer (kw) | |||||||||||||||||||
| LXPL-BHF-55M | RC2-200B -Z (55HP) | 1 | 35 | 91.9 | 33.6 | 113.1 | 34.9 | 137.6 | 36.1 | 166.1 | 37.3 | 198.9 | 38.2 | 100 | Φ42 | Φ76 | Φ42 | Φ54 | 2300×900×1100 |
| 40 | 85.7 | 36.6 | 105.7 | 38.1 | 129.4 | 39.5 | 156.5 | 40.8 | 187.8 | 41.9 | |||||||||
| 45 | 78.9 | 40.0 | 97.8 | 41.6 | 120.2 | 43.2 | 146.3 | 44.7 | 176.1 | 46.0 | |||||||||
| LXPL-BHF2 -110M | RC2-200B -ZP (55HP) | 2 | 35 | 183.8 | 67.2 | 226.2 | 69.8 | 275.2 | 72.2 | 332.2 | 74.6 | 397.8 | 76.4 | 200 | Φ57 | Φ108 | Φ76 | Φ76 | 2330×1700×1100 |
| 40 | 171.4 | 73.2 | 211.4 | 73.2 | 258.8 | 79.0 | 313.0 | 81.6 | 375.6 | 83.3 | |||||||||
| 45 | 157.8 | 80.0 | 195.6 | 83.2 | 240.4 | 86.4 | 292.6 | 89.4 | 352.2 | 92.0 | |||||||||
| LXPL-BHF3 -165M | 3 | 35 | 275.7 | 100.8 | 399.3 | 104.7 | 412.8 | 108.3 | 498.3 | 111.9 | 596.7 | 114.6 | 250 | Φ57 | Φ89×2 | Φ89 | Φ76 | 2300×1700×1800 | |
| 40 | 257.1 | 109.8 | 317.1 | 114.3 | 388.2 | 188.5 | 469.5 | 122.4 | 563.4 | 125.7 | |||||||||
| 45 | 236.7 | 120.2 | 293.4 | 124.8 | 360.6 | 129.6 | 438.9 | 134.1 | 528.3 | 138.0 | |||||||||
| LXPL-BHF4 -220 juta | M | 35 | 367.6 | 134.4 | 452.4 | 139.6 | 550.4 | 144.4 | 664.4 | 149.2 | 795.6 | 152.8 | 300 | Φ57 | Φ108 ×2 | Φ108 | Φ76 | 4400×1700×1800 | |
| 40 | 342.8 | 146.4 | 422.8 | 152.4 | 517.6 | 158.0 | 626.0 | 163.2 | 751.2 | 167.6 | |||||||||
| 45 | 315.6 | 160.0 | 391.2 | 166.4 | 480.8 | 172.8 | 585.2 | 177.8 | 704.4 | 184.0 | |||||||||
| LXPL-HF -60M | RC2-230B -Z (60HP) | 1 | 35 | 114.1 | 33.6 | 140.5 | 44.2 | 170.9 | 45.8 | 206.3 | 47.3 | 247.1 | 48.4 | 150 | Φ35 | Φ76 | Φ54 | Φ35 | 2300×900×1250 |
| 40 | 106.3 | 46.4 | 131.2 | 48.3 | 160.7 | 50.0 | 194.4 | 51.7 | 233.3 | 53.1 | |||||||||
| 45 | 97.9 | 50.7 | 121.4 | 52.8 | 149.3 | 54.7 | 181.7 | 56.6 | 218.8 | 58.2 | |||||||||
| LXPL-BHF2 -120 juta | RC2-230B -ZP (60HP) | 2 | 35 | 228.2 | 85.0 | 281.0 | 88.4 | 341.8 | 91.6 | 412.6 | 94.4 | 494.2 | 96.8 | 200 | Φ42 | Φ133 | Φ76 | Φ42 | 2600×1700×1900 |
| 40 | 212.6 | 92.8 | 262.4 | 96.6 | 321.4 | 100.0 | 388.8 | 103.4 | 466.6 | 106.2 | |||||||||
| 45 | 195.8 | 101.4 | 242.8 | 105.6 | 298.6 | 109.4 | 363.4 | 113.2 | 437.6 | 116.4 | |||||||||
| LXPL-BHF3 -180M | 3 | 35 | 342.3 | 127.5 | 421.5 | 132.6 | 512.7 | 134.7 | 618.9 | 141.6 | 741.3 | 145.2 | 300 | Φ54 | Φ108 ×2 | Φ76 | Φ67 | 3500×1700×1900 | |
| 40 | 318.9 | 139.2 | 393.6 | 144.9 | 482.1 | 150.0 | 583.2 | 155.1 | 699.9 | 159.3 | |||||||||
| 45 | 293.7 | 152.1 | 364.2 | 158.4 | 447.9 | 164.1 | 545.1 | 169.8 | 656.4 | 174.6 | |||||||||
| LXPL-BHF4 -240M | 4 | 35 | 456.4 | 170.0 | 562.0 | 176.8 | 683.6 | 183.2 | 825.2 | 188.8 | 988.4 | 193.6 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | |
| 40 | 425.2 | 185.6 | 524.8 | 193.2 | 642.8 | 200.0 | 777.6 | 206.8 | 933.2 | 212.4 | |||||||||
| 45 | 391.6 | 202.8 | 485.6 | 211.2 | 597.2 | 218.8 | 726.8 | 266.4 | 875.2 | 232.8 | |||||||||
| LXPL-HF -70M | RC2-260B -Z (70HP) | 1 | 35 | 123.4 | 43.8 | 151.3 | 45.6 | 184.1 | 47.2 | 222.2 | 448.7 | 266.1 | 49.9 | 150 | Φ35 | Φ76 | Φ54 | Φ35 | 2300×900×1250 |
| 40 | 114.7 | 47.9 | 141.5 | 49.8 | 173.1 | 51.6 | 209.3 | 53.3 | 251.3 | 54.7 | |||||||||
| 45 | 105.7 | 52.3 | 130.9 | 54.4 | 161.4 | 56.4 | 195.7 | 58.3 | 235.6 | 60.0 | |||||||||
| LXPL-BHF2 -140M | RC2-260B -ZP (70HP) | 2 | 35 | 246.8 | 87.6 | 302.6 | 91.2 | 368.2 | 94.4 | 444.4 | 97.4 | 532.2 | 99.8 | 200 | Φ54 | Φ133 | Φ76 | Φ54 | 2600×1700×1900 |
| 40 | 229.4 | 95.8 | 283.0 | 99.6 | 346.2 | 103.2 | 418.6 | 106.6 | 502.6 | 109.4 | |||||||||
| 45 | 211.4 | 104.6 | 261.8 | 108.8 | 322.8 | 112.8 | 391.4 | 116.6 | 471.2 | 120.0 | |||||||||
| LXPL-BHF3 -210M | 3 | 35 | 370.2 | 131.4 | 453.9 | 136.8 | 552.3 | 141.6 | 666.6 | 146.1 | 798.3 | 149.7 | 300 | Φ54 | Φ108 ×2 | Φ108 | Φ67 | 3500×1700×1900 | |
| 40 | 344.1 | 143.7 | 424.5 | 149.4 | 591.3 | 154.8 | 627.9 | 159.9 | 753.9 | 164.1 | |||||||||
| 45 | 317.1 | 156.9 | 392.7 | 163.2 | 484.2 | 169.2 | 587.1 | 174.9 | 706.8 | 180.0 | |||||||||
| LXPL-BHF4 -280M | 4 | 35 | 493.6 | 175.2 | 605.2 | 182.4 | 736.4 | 188.8 | 888.8 | 194.8 | 1064.4 | 199.6 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | |
| 40 | 458.8 | 191.6 | 566.0 | 199.2 | 692.4 | 206.4 | 837.2 | 213.2 | 1005.2 | 218.8 | |||||||||
| 45 | 422.8 | 209.2 | 523.6 | 217.6 | 645.6 | 225.6 | 782.8 | 233.2 | 942.4 | 240.0 | |||||||||
| Model Satuan | Kamera.Model | Com, Keakuratan | Kondensasi suhu (℃) | Suhu Penguapan. (℃) | waduk (kiri) | Pasokan pipa (mm) | Hisap pipa (mm) | Jalan Keluar Gas pipa (mm) | cair pipa masuk (mm) | Dimensi (mm) (P×L×T) | ||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||||||||||
| Kapasitas Pendinginan/Input Daya (kw) | ||||||||||||||||||||
| LXPL-BHF-75M | RC2-300B -Z (75HP) | 1 | 35 | 145.4 | 50.5 | 178.3 | 52.5 | 216.9 | 54.4 | 261.8 | 56.1 | 313.6 | 57.5 | 200 | Φ57 | Φ89 | Φ67 | Φ67 | 2300×900×1250 | |
| 40 | 135.3 | 55.2 | 167.3 | 57.4 | 203.9 | 59.5 | 246.6 | 61.4 | 296.1 | 63.1 | ||||||||||
| 45 | 127.4 | 60.3 | 154.4 | 62.7 | 190.1 | 65.1 | 230.6 | 67.3 | 277.6 | 69.2 | ||||||||||
| LXPL-BHF2 -150 juta | RC2-300B -ZP (75HP) | 2 | 35 | 290.8 | 101.0 | 356.6 | 105.0 | 433.8 | 108.8 | 523.6 | 112.2 | 627.2 | 115.0 | 250 | Φ57 | Φ133 | Φ89 | Φ76 | 2600×1700×1900 | |
| 40 | 270.6 | 101.0 | 334.6 | 114.8 | 407.8 | 119.0 | 493.2 | 122.8 | 5922 | 126.2 | ||||||||||
| 45 | 249.4 | 120.6 | 308.8 | 125.4 | 380.2 | 130.2 | 461.2 | 134.6 | 555.2 | 138.4 | ||||||||||
| LXPL-BHF3 -225 juta | 3 | 35 | 436.2 | 151.5 | 534.9 | 157.5 | 650.7 | 163.2 | 785.4 | 168.3 | 940.8 | 172.5 | 400 | Φ57 | Φ108 ×2 | Φ108 | Φ89 | 3500×1700×1900 | ||
| 40 | 405.9 | 165.6 | 501.9 | 172.2 | 611.7 | 178.5 | 739.8 | 184.2 | 888.3 | 189.3 | ||||||||||
| 45 | 374.1 | 180.9 | 463.2 | 188.1 | 570.3 | 195.3 | 691.8 | 201.9 | 832.8 | 207.6 | ||||||||||
| LXPL-BHF4 -300 juta | 4 | 35 | 581.6 | 202.0 | 731.2 | 210.0 | 867.6 | 217.6 | 1047.2 | 224.4 | 1254.4 | 230.0 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1700×1900 | ||
| 40 | 541.2 | 220.8 | 699.2 | 229.6 | 815.6 | 238.0 | 986.4 | 245.6 | 1184.4 | 252.4 | ||||||||||
| 45 | 498.8 | 241.2 | 617.6 | 250.8 | 760.4 | 260.4 | 922.4 | 269.2 | 1110.4 | 276.8 | ||||||||||
| LXPL-HF -80M | RC2-310B -Z (80HP) | 1 | 35 | 153.7 | 53.8 | 188.4 | 55.9 | 229.2 | 57.9 | 276.6 | 59.7 | 331.6 | 61.2 | 200 | Φ35 | Φ76 | Φ54 | Φ35 | 2600×900×1400 | |
| 40 | 142.9 | 58.7 | 176.8 | 61.1 | 215.5 | 63.3 | 260.6 | 65.3 | 312.8 | 67.1 | ||||||||||
| 45 | 131.7 | 64.1 | 163.1 | 66.7 | 200.9 | 69.2 | 243.7 | 71.6 | 293.3 | 73.6 | ||||||||||
| LXPL-BHF2 -160M | RC2-310B -ZP (80HP) | 2 | 35 | 307.4 | 107.8 | 376.8 | 111.8 | 458.4 | 115.8 | 553.2 | 119.4 | 662.6 | 122.4 | 250 | Φ57 | Φ133 | Φ76 | Φ54 | 3000×1800×2100 | |
| 40 | 285.8 | 117.4 | 353.6 | 122.2 | 431.0 | 126.6 | 521.2 | 130.6 | 625.6 | 134.2 | ||||||||||
| 45 | 263.4 | 128.2 | 326.2 | 133.4 | 401.8 | 138.4 | 487.4 | 143.2 | 586.6 | 147.2 | ||||||||||
| LXPL-BHF3 -240M | 3 | 35 | 461.1 | 161.4 | 565.2 | 167.7 | 687.6 | 173.7 | 829.8 | 179.1 | 993.9 | 183.6 | 400 | Φ54 | Φ108 ×2 | Φ108 | Φ67 | 3500×1700×1900 | ||
| 40 | 428.7 | 176.1 | 530.4 | 183.3 | 646.5 | 189.9 | 781.8 | 195.9 | 938.4 | 201.3 | ||||||||||
| 45 | 395.1 | 192.3 | 489.3 | 200.1 | 602.7 | 207.6 | 731.1 | 214.8 | 879.9 | 220.8 | ||||||||||
| LXPL-BHF4 -320M | 4 | 35 | 614.8 | 215.2 | 753.6 | 223.6 | 916.8 | 231.6 | 1106.4 | 238.8 | 1325.2 | 244.8 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4000×1700×1900 | ||
| 40 | 571.6 | 234.8 | 707.2 | 244.4 | 862.0 | 253.2 | 1042.4 | 261.2 | 1251.2 | 268.4 | ||||||||||
| 45 | 526.8 | 256.4 | 376.8 | 266.8 | 803.6 | 276.8 | 974.8 | 286.4 | 1173.2 | 299.4 | ||||||||||
| LXPL-HF -90M | RC2-340B -Z (90HP) | 1 | 35 | 171.1 | 58.0 | 209.8 | 60.3 | 255.2 | 62.5 | 308.0 | 64.4 | 368.9 | 66.1 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 2600×850×1400 | |
| 40 | 159.3 | 63.4 | 196.8 | 65.9 | 239.9 | 68.3 | 290.1 | 70.5 | 348.3 | 72.4 | ||||||||||
| 45 | 146.9 | 69.2 | 181.8 | 72.0 | 223.7 | 74.7 | 271.3 | 77.2 | 326.6 | 79.5 | ||||||||||
| LXPL-BHF2 -180M | RC2-340B -ZP (90HP) | 2 | 35 | 342.2 | 116.0 | 419.6 | 120.6 | 510.4 | 125.0 | 616.0 | 128.8 | 737.8 | 132.2 | 300 | Φ54 | Φ133 | Φ76 | Φ54 | 3000×1800×2100 | |
| 40 | 318.9 | 126.8 | 393.6 | 131.8 | 479.8 | 136.6 | 580.2 | 141.0 | 696.6 | 144.8 | ||||||||||
| 45 | 293.8 | 138.4 | 363.8 | 144.0 | 447.4 | 149.4 | 542.6 | 154.4 | 653.2 | 159.0 | ||||||||||
| LXPL-BHF3 -270M | 3 | 35 | 513.3 | 174.0 | 629.4 | 180.9 | 765.6 | 187.5 | 924.0 | 193.2 | 1106.7 | 198.3 | 400 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 3800×1800×2100 | ||
| 40 | 477.9 | 190.2 | 590.4 | 197.7 | 719.7 | 204.9 | 870.3 | 211.5 | 1044.9 | 217.2 | ||||||||||
| 45 | 440.7 | 207.6 | 545.4 | 216.0 | 671.1 | 224.1 | 813.9 | 231.6 | 979.8 | 238.5 | ||||||||||
| LXPL-BHF4 -360M | 4 | 35 | 684.4 | 232.0 | 839.2 | 241.2 | 1020.8 | 250.0 | 1232.0 | 2576 | 1475.6 | 264.4 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 4600×1800×2100 | ||
| 40 | 637.2 | 253.6 | 787.2 | 263.6 | 959.6 | 273.2 | 1160.4 | 282.0 | 1393.2 | 289.6 | ||||||||||
| 45 | 587.6 | 276.8 | 727.2 | 288.0 | 894.8 | 298.8 | 1085.2 | 308.8 | 1306.4 | 318.0 | ||||||||||
| Model Satuan | Com.Model | Com, Ketelitian | Kondensasi suhu. (℃) | Suhu Penguapan. (℃) | waduk (kiri) | Pasokan pipa (mm) | Hisap pipa (mm) | Jalan Keluar Gas pipa (mm) | cair pipa masuk (mm) | Dimensi (mm) (PxL×T) | ||||||||||
| -15 | -10 | -5 | 0 | 5 | ||||||||||||||||
| Kapasitas Pengumpulan/Input Daya (kw) | ||||||||||||||||||||
| LXPL-BHF -100 juta | RC2-370B -Z (100HP) | 1 | 35 | 184.3 | 62.7 | 226.0 | 65.2 | 274.8 | 67.5 | 331.7 | 69.6 | 397.3 | 71.3 | 100 | Φ42 | Φ108 | Φ67 | Φ57 | 2600×850×1400 | |
| 40 | 171.5 | 68.4 | 212.0 | 71.5 | 285.4 | 73.8 | 312.5 | 76.2 | 375.1 | 78.3 | ||||||||||
| 45 | 158.1 | 74.8 | 195.8 | 77.8 | 240.9 | 80.7 | 292.2 | 83.4 | 351.7 | 85.8 | ||||||||||
| LXPL-BHF2 -200 juta | RC2-370B -ZP (100HP) | 2 | 35 | 368.6 | 125.4 | 452.0 | 130.4 | 549.6 | 135.0 | 663.4 | 139.2 | 794.6 | 142.8 | 300 | Φ54 | Φ159 | Φ108 | Φ67 | 3500×1900×2100 | |
| 40 | 343.0 | 136.8 | 424.0 | 142.4 | 516.8 | 147.6 | 625.0 | 152.4 | 750.2 | 156.4 | ||||||||||
| 45 | 316.2 | 149.6 | 391.6 | 155.6 | 481.8 | 161.4 | 584.4 | 166.8 | 703.4 | 171.8 | ||||||||||
| LXPL-BHF3 -300 juta | 3 | 35 | 552.9 | 188.1 | 678.0 | 195.6 | 824.4 | 202.5 | 995.1 | 208.8 | 1191.9 | 214.2 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1900×2100 | ||
| 40 | 514.5 | 205.2 | 636.0 | 213.6 | 775.2 | 221.4 | 937.5 | 228.6 | 1125.3 | 234.6 | ||||||||||
| 45 | 474.3 | 224.4 | 587.4 | 233.4 | 722.7 | 242.1 | 876.6 | 205.2 | 1055.1 | 257.7 | ||||||||||
| LXPL-BHF4 -400M | 4 | 35 | 737.2 | 250.8 | 904.0 | 260.8 | 1099.2 | 270.0 | 1326.8 | 278.4 | 1589.2 | 285.6 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 5300×1900×2100 | ||
| 40 | 686.0 | 273.6 | 848.0 | 284.8 | 1033.6 | 295.2 | 1250.0 | 304.8 | 1500.4 | 312.8 | ||||||||||
| 45 | 632.4 | 299.2 | 783.2 | 313.2 | 963.6 | 322.8 | 1168.8 | 333.6 | 1406.8 | 343.6 | ||||||||||
| LXPL-HF -110M | RC2-410B -Z (110HP) | 1 | 35 | 200.4 | 69.3 | 245.9 | 72.1 | 298.8 | 67.5 | 360.6 | 77.0 | 432.0 | 78.9 | 250 | Φ42 | Φ108 | Φ67 | Φ54 | 2750×850×1450 | |
| 40 | 186.4 | 75.7 | 230.5 | 78.7 | 280.9 | 81.6 | 339.8 | 84.3 | 407.9 | 86.5 | ||||||||||
| 45 | 171.8 | 82.7 | 212.8 | 86.0 | 261.9 | 89.3 | 317.7 | 92.3 | 352.8 | 95.0 | ||||||||||
| LXPL-BHF2 -220 juta | RC2-410B -ZP (110HP) | 2 | 35 | 400.8 | 138.6 | 491.4 | 144.2 | 597.6 | 135.0 | 721.2 | 154.0 | 864.0 | 157.8 | 300 | Φ57 | Φ159 | Φ108 | Φ76 | 3500×1900×2150 | |
| 40 | 372.8 | 151.4 | 461.0 | 157.4 | 561.8 | 163.2 | 679.6 | 168.6 | 815.8 | 137.0 | ||||||||||
| 45 | 343.6 | 165.4 | 425.6 | 172.0 | 523.8 | 178.6 | 635.4 | 184.6 | 764.8 | 190.0 | ||||||||||
| LXPL-BHF3 -330M | 3 | 35 | 601.2 | 207.9 | 737.1 | 216.3 | 896.4 | 202.5 | 1081.8 | 231.0 | 1296.0 | 236.7 | 500 | Φ57 | Φ133 ×2 | Φ108 | Φ89 | 4400×1000×2150 | ||
| 40 | 559.2 | 227.1 | 691.5 | 236.1 | 842.7 | 244.8 | 1019.4 | 252.9 | 1223.7 | 259.5 | ||||||||||
| 45 | 515.4 | 248.1 | 638.4 | 258.0 | 785.7 | 267.9 | 953.1 | 276.9 | 1147.2 | 285.0 | ||||||||||
| LXPL-BHF4 -440M | 4 | 35 | 801.6 | 277.2 | 982.8 | 288.4 | 1195.2 | 270.0 | 1442.4 | 308.0 | 1728.0 | 315.6 | 600 | Φ57 | Φ159 ×2 | Φ133 | Φ89 | 5300×1900×2150 | ||
| 40 | 745.6 | 302.8 | 922.0 | 314.8 | 1123.6 | 326.4 | 1359.2 | 337.2 | 1631.6 | 346.0 | ||||||||||
| 45 | 687.2 | 330.8 | 851.2 | 344.0 | 1047.6 | 357.2 | 1270.8 | 369.2 | 1529.6 | 380.0 | ||||||||||
| LXPL-HF -125M | RC2-470B -Z (125HP) | 1 | 35 | 238.6 | 80.1 | 292.5 | 83.3 | 355.8 | 86.3 | 429.4 | 88.9 | 514.3 | 91.2 | 250 | Φ42 | Φ108 | Φ67 | Φ54 | 2750×870×1450 | |
| 40 | 222.2 | 87.5 | 274.4 | 91.0 | 334.5 | 94.3 | 404.5 | 97.3 | 485.6 | 100.0 | ||||||||||
| 45 | 204.8 | 95.5 | 253.6 | 994 | 311.9 | 103.1 | 378.3 | 106.6 | 455.3 | 109.7 | ||||||||||
| LXPL-BHF2 -250 juta | RC2-470B -ZP (125HP) | 2 | 35 | 477.2 | 160.2 | 585.0 | 166.6 | 711.6 | 172.6 | 858.8 | 177.8 | 1028.6 | 182.4 | 400 | Φ57 | Φ159 | Φ108 | Φ67 | 3500×1900×2550 | |
| 40 | 444.4 | 1750 | 548.8 | 182.0 | 699.0 | 188.6 | 809.0 | 194.5 | 971.2 | 200.0 | ||||||||||
| 45 | 409.8 | 191.0 | 507.2 | 198.8 | 623.8 | 206.2 | 756.6 | 213.2 | 910.6 | 219.4 | ||||||||||
| LXPL-BHF3 -375M | 3 | 35 | 715.8 | 240.3 | 877.5 | 249.9 | 1067.4 | 258.9 | 1288.2 | 266.7 | 1542.9 | 273.6 | 600 | Φ57 | Φ133 ×2 | Φ133 | Φ89 | 4500×1900×2500 | ||
| 40 | 666.6 | 262.5 | 838.2 | 273.0 | 1003.5 | 282.9 | 1213.5 | 291.9 | 1456.8 | 300.0 | ||||||||||
| 45 | 614.4 | 286.5 | 760.8 | 298.2 | 935.7 | 309.3 | 1134.9 | 319.8 | 1365.9 | 329.1 | ||||||||||
| LXPL-BHF4 -500 juta | 4 | 35 | 954.4 | 320.4 | 1170.0 | 333.2 | 1423.2 | 3452 | 1717.6 | 355.6 | 2057.2 | 364.8 | 800 | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5400×1900×2500 | ||
| 40 | 888.8 | 350.01 | 1097.6 | 364.0 | 1338.0 | 377.2 | 1618.0 | 389.2 | 1942.4 | 438.8 | ||||||||||
| 45 | 819.2 | 382.0 | 1014.4 | 397.6 | 1247.6 | 412.4 | 1513.2 | 426.4 | 1821.2 | 438.8 | ||||||||||
| Model Satuan | Com.Model | Kamera. Keakuratan | Kondensasi suhu. (℃) | Suhu Penguapan. (℃) | waduk (kiri) | Pasokan pipa (mm) | Hisap pipa (mm) | Jalan Keluar Gas pipa (mm) | cair pipa masuk (mm) | Dimensi (mm) (P×L×T) | |||||||||
| -15 | -10 | -5 | 0 | 5 | |||||||||||||||
| Kapasitas ColingInput Daya (kw) | |||||||||||||||||||
| LXPL-BHF -130M | RC2-510B -Z (130HP) | 1 | 35 | 254.3 | 85.9 | 311.9 | 89.3 | 379.3 | 92.5 | 457.8 | 95.4 | 548.3 | 97.8 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 236.8 | 93.8 | 292.6 | 97.5 | 356.6 | 101.1 | 431.3 | 104.4 | 517.7 | 107.2 | |||||||||
| 45 | 218.3 | 102.4 | 270.3 | 106.6 | 332.5 | 110.6 | 403.3 | 114.3 | 485.5 | 117.6 | |||||||||
| LXPL-BHF2 -260M | RC2-510B -ZP (130HP) | 2 | 35 | 508.6 | 171.8 | 623.8 | 178.6 | 758.6 | 185.0 | 915.6 | 190.8 | 1096.6 | 195.6 | 400 | Φ57 | Φ159 | Φ133 | Φ89 | 3250×2100×1750 |
| 40 | 473.6 | 187.6 | 585.2 | 195.0 | 713.2 | 202.2 | 862.6 | 208.8 | 1035.4 | 214.4 | |||||||||
| 45 | 436.6 | 204.8 | 540.6 | 213.2 | 665.0 | 221.2 | 806.6 | 228.6 | 971.0 | 235.2 | |||||||||
| LXPL-BHF3 -390M | 3 | 35 | 762.9 | 257.7 | 935.7 | 267.9 | 1137.9 | 277.5 | 1373.4 | 286.2 | 1644.9 | 293.4 | 600 | Φ76 | Φ133 ×2 | Φ159 | Φ89 | 4350×2100×1800 | |
| 40 | 710.4 | 281.4 | 877.8 | 292.5 | 1069.8 | 303.3 | 1293.9 | 313.2 | 1553.1 | 321.6 | |||||||||
| 45 | 654.9 | 307.2 | 810.9 | 319.8 | 997.5 | 331.8 | 1209.9 | 342.9 | 1456.5 | 352.8 | |||||||||
| LXPL-BHF4 -520M | 4 | 35 | 1017.2 | 343.6 | 1247.6 | 357.2 | 1517.2 | 370.0 | 1831.2 | 381.6 | 2193.2 | 391.2 | 800 (Di luar) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5400×2100×2050 | |
| 40 | 947.2 | 375.2 | 1170.4 | 390.0 | 1426.4 | 404.4 | 1725.2 | 417.66 | 2070.8 | 428.8 | |||||||||
| 45 | 873.2 | 409.6 | 1081.2 | 426.4 | 1330.0 | 442.4 | 1613.2 | 457.2 | 1942.0 | 470.4 | |||||||||
| LXPL-HF -140M | RC2-550B -Z (140HP) | 1 | 35 | 271.3 | 94.4 | 322.6 | 98.2 | 404.6 | 101.7 | 488.3 | 104.9 | 584.8 | 107.5 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 252.3 | 103.1 | 312.1 | 107.3 | 380.3 | 111.2 | 460.0 | 114.8 | 552.2 | 117.9 | |||||||||
| 45 | 232.5 | 112.7 | 288.0 | 117.2 | 354.6 | 121.6 | 430.1 | 125.7 | 517.8 | 129.4 | |||||||||
| LXPL-BHF2 -280M | RC2-550B -ZP (140HP) | 2 | 35 | 542.6 | 188.8 | 665.2 | 196.4 | 809.2 | 203.4 | 976.6 | 209.8 | 1169.6 | 215.0 | 400 | Φ57 | Φ159 | Φ133 | Φ89 | 3400×2150×1750 |
| 40 | 504.6 | 206.2 | 624.2 | 214.6 | 760.6 | 222.4 | 920.0 | 229.6 | 1104.4 | 235.8 | |||||||||
| 45 | 465.0 | 225.4 | 576.0 | 234.4 | 709.2 | 243.2 | 860.2 | 251.4 | 1035.6 | 258.8 | |||||||||
| LXPL-BHF3 -420M | 3 | 35 | 813.9 | 2832 | 997.8 | 294.6 | 1213.8 | 305.1 | 1464.9 | 314.7 | 1754.4 | 322.5 | 600 | Φ76 | Φ133 ×2 | Φ159 | Φ89 | 4550×2150×2050 | |
| 40 | 765.9 | 309.3 | 936.3 | 321.9 | 1140.9 | 333.6 | 1380.0 | 344.4 | 1656.6 | 353.7 | |||||||||
| 45 | 697.5 | 338.1 | 864.0 | 351.6 | 1063.8 | 364.8 | 1290.3 | 377.1 | 1553.4 | 388.2 | |||||||||
| LXPL-BHF4 -560M | 4 | 35 | 1085.2 | 377.6 | 1330.4 | 392.8 | 1618.4 | 406.8 | 1953.2 | 419.6 | 2339.2 | 430.0 | 800 (Di luar) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5600×2150×2050 | |
| 40 | 1009.2 | 412.4 | 1248.4 | 4292 | 1521.2 | 444.8 | 1840.0 | 459.2 | 2208.8 | 471.6 | |||||||||
| 45 | 930.0 | 450.8 | 1152.0 | 466.8 | 1418.4 | 486.4 | 1720.4 | 502.8 | 2071.2 | 517.6 | |||||||||
| LXPL-HF -150 juta | RC2-580B -Z (150HP | 1 | 35 | 299.9 | 101.6 | 367.7 | 105.7 | 447.2 | 109.5 | 539.8 | 112.9 | 646.5 | 115.8 | 200 | Φ42 | Φ108 | Φ67 | Φ54 | 3050×870×1450 |
| 40 | 279.2 | 111.0 | 345.0 | 115.5 | 420.4 | 119.7 | 508.5 | 123.6 | 610.4 | 126.9 | |||||||||
| 45 | 257.4 | 121.3 | 318.6 | 126.2 | 392.0 | 130.9 | 475.5 | 135.3 | 572.4 | 139.3 | |||||||||
| LXPL-BHF2 -300 juta | RC2-580B -ZP (150HP) | 2 | 35 | 599.8 | 203.2 | 735.4 | 211.4 | 894.4 | 219.0 | 1079.6 | 225.8 | 1293.0 | 231.6 | 500 | Φ57 | Φ159 | Φ133 | Φ89 | 3500×2150×1750 |
| 40 | 558.4 | 222.0 | 690.0 | 231.0 | 840.8 | 239.4 | 1017.0 | 247.2 | 1220.8 | 253.8 | |||||||||
| 45 | 514.8 | 242.6 | 637.2 | 252.4 | 784.0 | 261.8 | 951.0 | 270.5 | 1144.8 | 278.5 | |||||||||
| LXPL-BHF3 -450 juta | 3 | 35 | 899.7 | 304.8 | 1103.1 | 317.1 | 1341.6 | 328.5 | 1619.4 | 338.7 | 1939.5 | 347.4 | 800 (Di luar) | Φ76 | Φ133 ×2 | Φ133 | Φ108 | 4650×2150×2050 | |
| 40 | 837.6 | 333.0 | 1035.0 | 346.51 | 1261.2 | 359.1 | 1525.5 | 370.8 | 1831.2 | 380.7 | |||||||||
| 45 | 772.2 | 363.9 | 955.8 | 378.6 | 1176.0 | 392.7 | 1426.5 | 405.9 | 1717.2 | 417.9 | |||||||||
| LXPL-BHF4 -600M | 4 | 35 | 1199.6 | 406.4 | 1470.8 | 422.8 | 1788.8 | 438.0 | 2159.2 | 451.6 | 2586.0 | 463.2 | 800 (Di luar) | Φ76 | Φ159 ×2 | Φ159 | Φ108 | 5800×2150×2350 | |
| 40 | 1116.8 | 444.0 | 1380.0 | 462.0 | 1681.6 | 478.8 | 2034.0 | 494.4 | 2441.6 | 507.6 | |||||||||
| 45 | 1029.6 | 485.2 | 1274.4 | 504.8 | 1568.0 | 5236 | 1902.0 | 541.2 | 2289.6 | 557.2 | |||||||||
Tampilan Detail
Hubungi Kami
TENTANG KAMI
Zhejiang Lanxi Refrigeration Equipment Co., Ltd.
Sebagai China Satuan Suhu Sedang hingga Tinggi Hanbell Pemasok dan Satuan Suhu Sedang hingga Tinggi Hanbell Pabrik,
Zhejiang Lanxi Refrigeration Equipment Co., Ltd. mengkhususkan diri dalam solusi pendinginan yang efisien, hijau, dan berkelanjutan. Dengan memanfaatkan produk berkualitas tinggi dan teknologi inovatif, kami melayani sektor makanan, farmasi, kimia, dan logistik rantai dingin, menciptakan sistem yang hemat energi dan ramah lingkungan bagi pelanggan kami serta mendorong perkembangan yang saling menguntungkan bagi industri dan lingkungan.
Sertifikat Penghargaan
Berita
-
Masuklah ke ruang penyimpanan dingin dan rasakan udara di dekat pintu. Jika salah satu sudut lebih hangat dibandingkan sudut lainnya, atau suhu meningkat setiap sore, pendingin udara industri yang dipasang di dalam ruangan biasanya me...
BACA SELENGKAPNYA -
Ketika sebuah pabrik pengolahan makanan di wilayah yang kekurangan air mengevaluasi opsi pendinginannya, pilihan kondensor sering kali menentukan apakah proyek tersebut disetujui. Kondensor berpendingin udara sepenuhnya menghilangkan ...
BACA SELENGKAPNYA -
Saat mencari a produsen evaporator dan kondensor , Pendinginan Lanxi tentu patut Anda perhatikan. Dengan keunggulan khas dalam desain dan produksi kondensor, Lanxi Refrigeration menghadirkan kondensor yang memiliki kinerja pertuka...
BACA SELENGKAPNYA
HUBUNGI KAMI
TAUTAN CEPAT
PRODUK
INFORMASI KONTAK
- Email: [email protected]
- Telepon: +86-15258555916
- Alamat: 301 Punan Avenue, Jalan Pukou, Kota Shengzhou, Kota Shaoxing, Provinsi Zhejiang.China
Hak Cipta © Zhejiang Lanxi Refrigeration Equipment Co., Ltd. Hak Cipta Dilindungi.
浙ICP备2022034605号-1
Grosir Satuan Suhu Sedang hingga Tinggi Hanbell Pabrik
